It is widely used in industries such as laser marking and laser welding, primarily targeting mid-to-low-end applications. It can meet 90% of the general marking requirements in the market and is one of the most cost-effective laser scanning galvanometers in the industry.
Product advantages
● High cost-effectiveness
In addition to its highly competitive price, it inherits most of the excellent performance of the high-end vibration mirror family of Zhibo Tech, overturning the traditional concept of cheap but no good goods.
● High-speed
Laser marking has a fast speed and can meet most general marking needs.
● High linearity
It has good linearity and can meet most application requirements with simple pillow distortion correction and proportional correction.
● Low-temperature bleaching
It has a lower zero temperature drift, gain temperature drift, and long-term temperature drift, and will not exhibit misalignment or other phenomena in general marking and welding.
● High stability
Our company has a complete product quality control system, and our products have undergone market baptism, with consistent quality. We have a good reputation in the laser industry through word of mouth.
Product Parameters | |
Input aperture |
10mm |
Scan angle |
±0.35rad |
Nonlinearity |
<0.5mrad |
Tracking error time |
0.2ms |
Small step long response time |
0.4ms |
Repeatability （RMS） |
<2urad |
Gain drift |
<50ppm/K |
Zero drift |
<30urad/K |
8 hour temperature drift |
<0.1mrad |
Marking speed |
<4m/s |
Positioning speed |
<10m/s |
Power supply |
±15V/3A |
Input Signal Protocol |
XY2-100 |
Laser wavelength |
355nm/532nm/1064nm/10600nm |
Operating temperature |
25±10(°C) |
Dimension（mm） |
110x87x85 |
Weight |
1.3 kg |
|
|
