It is very suitable for continuous laser cleaning under high speed, high intensity, and complex working conditions. It is mainly loaded on automation scenarios such as XYZ motion platforms or robotic arms, and can meet the requirements of long continuous working hours, high humidity in the working environment, and fast cleaning efficiency.
Product advantages
● High power
Using specially customized high-power optical lens components, combined with efficient water cooling structure and multi-level temperature protection, it can stably withstand up to 12000W continuous laser power, and easily deal with various stubborn stains.
● High efficiency
Equipped with high-speed high-power water-cooled motor, high-speed driver and high-efficiency water-cooled field mirror, it has fast cleaning speed and high efficiency, while ensuring the stability of system operation.
● High stability
It adopts multi-level anti-interference design and multi-level closed-loop control algorithm to effectively resist electromagnetic interference and mechanical vibration; the body meets the IP6 dustproof standard to ensure that the galvo can operate stably for a long time in harsh environments.
● Large format
Large cleaning range, up to 1000mm x 1000mm, to meet the needs of efficient cleaning of large workpieces.
Product Parameters | ||||
NAME |
ZB2DFHSC20GW1064 |
ZB2DFHSC25GW1064 |
ZB2DFHSC30GW1064 |
|
Laser wavelength |
1064nm |
1064nm |
1064nm |
|
Input aperture |
20mm |
30mm |
30mm |
|
Scan angle |
±0.35rad |
±0.35rad |
±0.35rad |
|
Nonlinearity |
<0.5mrad |
<0.5mrad |
<0.5mrad |
|
Tracking error time |
0.4ms |
0.5ms |
0.55ms |
|
Angular velocity |
<190 rad/s |
<155 rad/s |
<130 rad/s |
|
Maximum power @1064nm |
3000W |
6000W |
8000W |
|
Cleaning range |
<1000 |
<1000 |
<1000 |
|
Repeatability |
<3urad |
<3urad |
<3urad |
|
Long-term axis drift |
<0.1mrad |
<0.1mrad |
<0.1mrad |
|
Cooling method |
Water-cooling |
Water-cooling |
Water-cooling |
|
Power supply |
±24V/14.6A |
±24V/14.6A |
±24V/14.6A |
|
Signal protocol |
XY2-100 |
XY2-100 |
XY2-100 |
|
Operating temperature |
25±10(°C) |
25±10(°C) |
25±10(°C) |
|
Storage temperature |
-10 to 60° |
-10 to 60° |
-10 to 60° |
|
Dimension(mm) |
110x79x280 |
200x197x158 |
200x197x158 |
|
|
||||
